HLT

Blogs

20
Aug 2024

Helium Leak Detector Calibration Standards Offered by PTI’s Helium Leak

Helium Leak Detector Calibration Standards Offered by PTI’s Helium Leak

Container Closure Integrity Testing (CCIT) is one of the most effective methods used by manufacturers to ensure that their products are sterile until the point of use. Testing the integrity of container closures determine if they can maintain a sterile barrier against potential contaminants that might impair the quality of the final pharmaceutical and biological products. There are several ways to perform tests on the integrity of container closures, each having advantages and limitations of its own. For instance, methods such as dye ingress and microbiological ingress damage the test samples. Therefore, manufacturers choose deterministic methods such as helium leak detection for package integrity testing.

Helium leak testing is the process of identifying leaks in some type of sealed or enclosed systems by utilizing helium as a "tracer" gas and monitoring the concentration of the gas as it leaves as a result of a leak. In this method, the package is helium-filled and placed under vacuum. A helium leak detector is used to monitor the volume of helium that is leaving the package quantitatively. The result is expressed as leak rate.

Helium Leak Detector

Helium leak detector, commonly referred to as a Mass Spectrometer Leak Detector (MSLD), is used to identify leaks that enter or leave a system or containment device and to measure its size. Helium, the tracer gas, is introduced into a test component that is attached to the leak detector. The system allows the helium that is leaking through the test portion to enter, and this partial pressure is monitored. The results are then displayed on a meter.

For a number of reasons, helium is the ideal tracer gas to locate leaks. It is non-toxic, inert, non-condensable, non-flammable, and just traces of it are often found in the atmosphere (5 ppm). Helium is a gas that quickly passes through leaks due to its tiny atomic size. The only non-inert molecule smaller than helium is hydrogen. It comes in several size cylinders and is also relatively inexpensive.

Explain Various Calibration Standards Offered by PTI's Helium Leak

PTI's Helium Leak offers complete sets of calibrated helium leak standards in addition to instruments and accessories to provide routine usage, daily performance verification or system suitability checks, and scheduled qualifications.

Internal Leak Standards:

An internal helium leak standard is included with every PTI SIMS 1915+ leak detection system. This apparatus is calibrated to discharge a certain amount of helium at a defined leak rate. It is utilized either on demand for a point-of-use auto calibration before analysis or automatically by the instrument on each day of usage.

External Leak Standards:

Every external helium leak standard developed by PTI's Helium Leak releases helium at a known leak rate, much as the internal leak standards. They attach to the test port, much like a sample fixture would be mounted to the system, rather than residing inside the instrument. The external nature of these leaks makes them perfect for routine PV or SS activities as well as qualification activities to assess the accuracy of the system. It is possible to perform an industry-standard, multi-point check across leak rate ranges of interest, since external leak standards are accessible in a variety of leak rates.

With every new instrument purchase, PTI's Helium Leak provides the following Internal and External Leak Standards (with certifications of calibration):

  • External Helium Leak Standard E-6 3 x 10 -6.
  • Internal Leak Standard - Set at E-7 1 x 10 -7.
  • External Helium Leak Standard E-7 3 x 10 -7.
  • External Helium Leak Standard E-8 3 x 10 -8.

A certificate of calibration that details the standards to which the leak was tested and the tolerance range for which that leak is certified should be attached to every calibrated helium leak. PTI's Helium Leak provides both external and internal leak standards with certificates of calibration.

Readmore...
helium leak detector, helium leak detection, helium leak testing
200
15
Sep 2022

SIMS 1915+ Helium Leak Detection System and its Applications

SIMS 1915+ Helium Leak Detection System and its Applications

USP <1207> Package Integrity Evaluation of Sterile Products provides an overview of relevant and authorized test procedures that may be utilized to achieve certification criteria. Developing a basic knowledge of these methodologies will allow you to make an informed decision on the most effective test methodology for a specific container and package system. Various CCI test methods are available today. Among them, helium leak testing has proven to be the most chosen method due to its extreme test sensitivity.

Why Use SIMS 1915+ for Leak Detection?

Seal Integrity Monitoring System (SIMS) 1915+ is the perfect choice for a helium-based leak detection system. Using helium as the tracer gas, packages may be quantitatively analyzed to levels much above the vacuum bubble and dye penetration test processes. This quantitative technique supports the entire lifetime by providing direct comparison across numerous packing materials and types, production line settings, and stable storage conditions. SIMS 1915+ can be used for package design, tooling qualification, manufacturing line setup, and continuous product quality monitoring. Each SIMS 1915+ helium leak testing equipment is built to the customer's specifications. SIMS 1915+ can do quantitative CCI analyses on packages with sensitivity as low as 1 x 10 -10 mbar L/s.

What are the Applications of SIMS 1915+?

  • Vials
  • Vials composed of glass and polymer are the most widely used package systems tested using helium leak detection. Vials are provided with a variety of capping to fulfill specific storage or handling needs. Vials are commonly used to store drugs or laboratory samples. Micro leaks in vials that carry sensitive drugs cannot be detected with a visual inspection. Helium leak testing is an ideal method for component qualification for empty components as well as a product-filled vial.

  • Pre-filled syringes
  • The use of pre-filled syringes has increased significantly in the pharmaceutical industry. CCI analyses of pre-filled syringes are more complicated, but they are much more important in ensuring entire system integrity. Helium leak testing for leak detection of pre-filled syringes has proven to be an effective method for evaluating the CCI of pre-filled syringes.

  • Bottles
  • Bottles made of glass or plastic are cost-effective traditional dosage forms ideal for the oral administration of syrups, solutions, and suspensions. Helium leak testing offered by LDA, a PTI company, quickly and effectively tests bottles for leaks and thereby defective bottles can be removed from the production line easily.

  • Blister packs
  • Due to the extreme sensitivity offered, the helium-based test method for evaluating the integrity of a blister card containing solid dose pharmaceutical drugs has been proven to be the most effective approach. Helium remains an ideal test method for qualifying the material components of CFF blister cards.

  • Foil pouches
  • Pharma manufacturers typically use foil pouches when a drug product requires multi-layered packaging. Helium leak testing of foil pouches is a viable and highly sensitive approach to meet strict regulatory requirements.

  • Combination products
  • These are multi-chamber systems that require unique test requirements. Helium Leak Detection as per ASTM F2391 is a well-established and widely used method for testing combination products. Testing combination products using helium leak testing ensure all components meet the strict leak rate requirements.

LDA’s (a PTI company) Seal Integrity Monitoring System (SIMS) 1915+ is an efficient method for a wide range of package types such as pre-filled syringes, cold form blister cards, foil pouches, parenteral vials, and unique medical devices. Seal Integrity Monitoring System (SIMS) Model 1915+ Helium Based Leak Testing System is designed specifically for the needs of the pharmaceutical and medical device industries.

Readmore...
helium leak testing equipment, helium leak detection, helium leak testing, helium leak detector, lda
876
13
Sep 2022

Evaluating Integrity of Vials Using Low Temperature Test Systems

Evaluating Integrity of Vials Using Low-Temperature Test Systems

With the rapid growth of the cell and gene therapy sector, there is a higher demand than ever to prove Container Closure Integrity (CCI) at low temperatures. Most cell and gene therapy drugs are maintained at temperatures below -60°C to preserve the effectiveness of the product. Many of these items are packed in vials or cryogenic freezing bags. Vials made of glass or plastic are the most commonly used containers for packing. They are used to preserve pharmaceuticals or laboratory samples. Each of these container closure systems presents a unique challenge for determining CCI at low temperatures. In this blog, we will discuss how the integrity of vials can be tested using low-temperature package test systems.

Low-Temperature Test Systems for Vial Integrity Testing

The most common challenge in storing vial systems at ultra-low temperatures is the occurrence of transient leaks. While a vial system may achieve leak rates at or below the maximum permissible leakage limit (MALL) at room temperature, the same may not necessarily be true at -80°C or lower. However, many of the materials used in these package systems and those responsible for maintaining the integrity of the package are not normally evaluated at these temperatures. Physical changes can occur, especially in elastomeric elements, when in contact with deep-cold or ultra-cold temperatures, causing the material to reach its glass transition state or higher. This results in leakage at low temperatures, which is not observed at room temperature. This type of leakage is most commonly found in primary sealing areas between elastomeric closures and glass vial, such as below -60°C. Having a reliable method to test container closure integrity while at these low temperatures enables manufacturers to minimize leakage.

LDA has developed the LT80, low temperature -80°C add-on test system for use with LDA SIMS helium leak detector to meet market demand for cold temperature leak analysis. Concurrent temperature conditioning, temperature monitoring and helium leak testing of packages approaching -80°C are all possible on the LT80 system. Helium leak detection is an effective way to ensure container closure integrity, even at temperatures below -80°C. Although there are alternative methods for measuring CCI, many of them are ineffective at temperatures below -80°C. LT150 low-temperature add-on unit allows sample testing at temperatures as low as -150°C.

Applications of Helium Leak Detection

  • Ensuring container closure integrity.
  • Seal integrity monitoring during stability studies.
  • Verify and predict shelf-life seal integrity.
  • Useful in the early stages of developing a drug product packaging system.
  • Selecting closure formulation and configuration.

Helium leak detection is a rapid, efficient, and deterministic method of determining the inherent CCI of a vial system at any temperature. Due to the sensitivity of helium leak detection, it is excellent for testing CCI for products that must retain both headspace gas and sterility. During the package development phase of the product life cycle, helium leak detection is most commonly utilized in evaluating component performance at ultra-low temperatures.

Readmore...
helium leak testing, helium leak detector, helium leak detection, helium mass spectrometry, helium CCIT
890
09
Sep 2022

Bottle Leak Testing Using Helium - Tracer Gas Method

Bottle Leak Testing Using Helium - Tracer Gas Method

Pharmaceutical bottle integrity testing is an important step in assuring that the product is safe and unadulterated. It analyzes the strength and integrity of the closure mechanism as well as its capacity to maintain a sterile barrier. Container closure integrity testing analyzes the materials and chemicals for the possibility of migration or leaching into the drug product, resulting in contamination. Microorganisms, gases, and other chemicals are examples of contaminants. Container system integrity testing involves evaluating primary packaging, or everything that comes into direct touch with the product, as well as secondary packaging components required for package assembly. Helium leak detection, airborne ultrasound, vacuum decay, and high voltage leak detection are all methods for verifying the safety of container closures.

Helium Leak Detection to Ensure the Integrity of Bottles

Helium leak detection is referred to as a method of finding leaks in a sealed or enclosed system using the helium tracer gas method. The amount of helium that leaks through a breach is measured and is stated as a leak rate. It is an effective container closure integrity test technique for determining the integrity of pharmaceutical and parenteral products. Helium leak testing guarantees the sterility of drug substances and drug products packaged and, therefore, enhances patient safety.

In this method, the package is filled with helium and subjected to vacuum. The quantity of helium that exits the package is measured using a helium leak detector. The result is expressed as the leak rate. Helium leak testing, in addition to being a highly sensitive container closure integrity test technique, is also useful in product design, product quality analyses, failure analysis, and validation.

What are the Applications of Helium Leak Testing?

Some of the most important applications of helium leak testing include:

  • Ensuring container closure integrity.
  • Selecting closure formulation and configuration.
  • Seal integrity monitoring during stability studies.
  • Verification and prediction of shelf-life seal integrity.
  • Useful in the early stages of developing a pharmaceutical product packaging system.

Helium leak detection offered by LDA (a PTI company) is one of the commonly used leak testing methods that can be used for pharmaceutical package leak detection. Bottles can be tested very effectively using this method. The applications of helium leak detection are also found in vials, prefilled syringes, foil pouches, and cold form blister cards. LDA has long-time expertise in designing leak testing equipment for pharmaceuticals and medical devices.

Readmore...
helium leak detection, helium leak testing, pharmaceutical package leak detection, pharmaceutical leak detection, helium leak detector
983
06
Sep 2022

Helium Mass Spectrometry for Leak Testing Foil Pouches

Helium Mass Spectrometry for Leak Testing Foil Pouches

Foil pouches are a simple solution for sterile barrier packaging. These are ideal for medical equipment and pharmaceuticals as well. Aluminum foil, which is impermeable to moisture, oxygen, and other gases, as well as microorganisms and light, helps to preserve pharmaceuticals in perfect condition for a longer period of time. These materials are used to create films that are free of contaminants and toxins. As a result, one advantage of foil pouches is that they may be used to package both food and non-food products. Another benefit of utilizing foil pouches is their low cost. Foil pouches are less expensive than many packaging materials.

Leak testing foil pouches is a challenging process. Leaking pouches may destroy the quality of the product by destroying the outside package. More significantly, leaking pouches provide a point of entry for contamination into the product, which can result in product degradation and potential health risks for patients. This creates the necessity of testing foil pouches and helps assure package quality.

How Helium Mass Spectrometer Detect Leaks in Foil Pouches?

Helium leak testing is a CCI testing method for leak testing foil pouches. It is the process of finding leaks in an enclosed system using helium as the tracer gas. Helium leak testing is one of the most accurate and rapid leak detection methods which employ a mass spectrometer for analyzing/measuring leaks. For a variety of reasons, helium gas is used to locate leaks. These include the fact that it is present only 5 ppm in air, resulting in very low background levels. Helium has a low mass and is completely inert/non-reactive. Helium is also non-flammable, abundantly available, and inexpensive.

Helium mass spectrometer is a device that helps in detecting and locating leaks. The device being tested is either pressurized from the inside or pressurized with helium from the outside. The gas from any possible leaks is collected and pumped into the mass spectrometer for analysis, and any value over the helium background trace indicates a leak. The mass spectrometer works as follows-any helium molecules vacuumed into the spectrometer are ionized, and these helium ions then fly into the ion trap, where the ion current is measured and recorded. The leak rate is then calculated using the ionization current.

Benefits of Helium Leak Testing

  • Identification and measurement of leaks with high sensitivity.
  • The majority of the testing is done in a dry, temperature-independent environment.
  • Reduced cost and processing time with shorter cycle time.
  • Due to the inert properties of helium, no effect on the substances under test.

Helium mass spectrometry is ideally suited for determining the intrinsic integrity of a packaging system. Helium mass spectrometer leak detection system for foil pouches offered by LDA (a PTI company) can be used to identify both large and small leaks. These are often employed in a vacuum chamber containing a sealed container filled with helium. Because of its non-toxic nature, helium is one of the important gases that may be used to identify leaks.

Readmore...
helium mass spectrometry, helium leak testing, helium leak detection, leak detection by mass spec, helium leak detector
1034
08
Feb 2022

Head Space Analyzer Module for Quality Control Leak Testing

Head Space Analyzer Module for Quality Control Leak Testing

Helium leak testing is a non-destructive method to verify the presence of a leak in a component or device by using helium as a tracer gas. Being a highly sensitive method, it measures the amount of helium escaping through the package and is stated as a leak rate. Helium leak detection using Seal Integrity Monitoring System (SIMS) 1915+ is widely used in pharmaceutical and medical device product package systems for quality checking. SIMS 1915+ enable quantitative CCI analyses of packages at a sensitivity level as low as 1 x 10-10 mbar/L/sec. This quantitative method enables direct comparison across multiple packaging materials and formats, production line settings, and stability storage conditions. Each SIMS 1915+ Helium Leak Testing device is custom-built to meet the specifications and packaging configurations of the client. The following are the SIMS 1915+ configurations for CCI.

  • Headspace Analyzer Module (HSAM)
  • Helium Leak Detector Module
  • External Calibrated Helium Leak Standard
  • Dual Test Port Manifold
  • Vacuum Test Fixture Model (VTFM)

Quality Control Leak Testing using LDA's Head Space Analyzer Module

The Head Space Analyzer Module (HSAM) is a critical component of a Leak Detection Associates (LDA) custom helium leak testing system. The Model VM-2, created by Leak Detection Associates, is the most recent version of this unique device. The HSAM includes a probe, which is essential for determining the helium concentration in the headspace of the container system. This system is simple to use and operate since it has an Integral Calibration Chamber with a Calibrant Gas Flow Control Valve and a Universal Holder that allows multiple diameter systems to be evaluated. Leak Detection Associates will provide three (3) Puncture Probes (two spares) with each unit.

The optional vial filling component enables the test preparation of already-sealed vials by replacing the headspace gas with 100% helium. This module can be used to prepare samples at the moment of testing, after capping, or to prepare samples that have been stored for a period of time prior to testing. When combined with the VM-2, these unique attachments enable accurate and sample-specific readings that may be integrated into flexible study designs.

Uses of Helium Leak Detection

  • Ensuring container closure integrity.
  • Seal integrity monitoring during stability studies.
  • Verify and predict shelf-life seal integrity.
  • Useful in the early-stage drug product package system development.
  • Selecting closure formulation and configuration.

LDA's Head Space Analyzer Module (HSAM) - SIMS 1915+ configuration ensures highly sensitive leak detection of pharmaceutical pouches. Cold form blister cards, parenteral vials, cartridges, pre-filled syringes, bottles, combination product systems, and medical device products are other applications.

Readmore...
helium leak detector, helium leak testing, helium leak detection, helium mass spectrometry, sims 1915+
1238
03
Feb 2022

How to Evaluate Helium Leak Rate Method for Pharmaceutical Containers?

How to Evaluate Helium Leak Rate Method for Pharmaceutical Containers?

Pharmaceutical containers can be tested for Container Closure Integrity (CCI) in a variety of ways. Blue dye test and bacterial or microbial immersion test come under traditional, probabilistic methods. Whereas Vacuum Decay, Airborne Ultrasound, MicroCurrent HVLD, and Helium Leak Detection belong to the deterministic group of test methods. Each approach has advantages and disadvantages that should be considered while selecting a test method for a certain container type. All the methods are not appropriate for all sample configurations. Some succeed in certain applications while failing in others. Nowadays, the pharmaceutical industry is moving away from the traditional blue dye and bacterial immersion test methods and approaching deterministic methods for CCI testing.

The helium leak rate method is proven to be a strong contender for many applications. Helium leak testing is described as the process of detecting leaks in various enclosed or sealed systems by utilizing helium as a "tracer" gas and measuring its concentration as it leaves due to leakage. Like most CCI methods, Helium Leak Detection is deterministic. This method is more sensitive and not prone to contamination as compared to traditional dye or bacterial immersion methods. Due to its highly sensitive nature, it is possible to detect extremely small leaks, which are not possible with other leak testing methods.

Validating Helium Leak Rate Method for Pharmaceutical Containers

Validation of a Helium leak rate method for pharmaceutical container closure integrity assurance required proof that this physical testing method was as excellent as, if not better than, microbial immersion challenge testing in detecting potential integrity problems. Helium leak rate and microbial challenge tests were performed on one lot of rubber-stopper, broth-filled glass vials, which include faulty vials with known leaks. Glass micropipettes (0.1 to 10 microns) were fitted into the sidewalls of the vials to prepare defective vials. A 10% seeded defect rate was present in the validation lot, with nearly 50% of the leaks having a predicted probability of failing a microbial challenge (> 10%). The test units were charged for 4 hours under 40 psi helium pressure to implant the helium tracer in them. After charging, the crucial leak rate was found to be 10(-7) standard cc/second, and test units with measured leak rates exceeding this value were considered helium leak rate failures.

Microbial immersion challenge was performed by immersing the test units for 24 hours in a bath containing 10(9-10) viable E. coli and B. diminuta organisms, followed by a 13-day incubation period at 35°C. Visually, microbial failures were identified. The mean failure rates of the helium and microbial leak test techniques were compared statistically. The average helium failure rate was 6.9%, whereas the average microbial failure rate was 2.8%. There was a considerable difference between helium and microbial failure rates. As a result, helium leak rate testing has been shown to be an acceptable pharmaceutical container/closure integrity method for container quality assurance.

The helium leak detection method is chosen to be one of the best techniques for ensuring the integrity of pharmaceutical containers. This technique may be used to test the inherent package integrity and the Maximum Allowable Leakage Limit (MALL) during package development. It is applicable to a wide range of package types, can locate leaks, and can measure leak flow rates directly.

Readmore...
helium-based leak detection systems, helium leak testing, helium leak detection, helium mass spectrometry, helium leak detector
1146
27
Jan 2022

Role of Helium Leak Detection in Vial Leak Testing

Role of Helium Leak Detection in Vial Leak Testing

Container Closure Integrity Testing (CCIT) is essential for maintaining the sterility and stability of sterile injectable products. The optimal test method varies depending on the product. CCI testing is used to determine if there is a leak between the contents of a container and its external environment. This can be done by identifying whether communication can be established between the contents of the container and its surroundings.

Pharmaceutical containers such as vials, syringes, cartridges, and blister packs are frequently tested as part of a stability study to ensure that the closure of the container can maintain a sterile barrier. As part of a stability testing methodology, the Food and Drug Administration (FDA) suggests performing a container closure integrity test instead of a sterility test. Primary packaging methods based on vials for sterile pharmaceutical products must provide protection over the shelf life. This necessitates the demonstration of Container Closure Integrity (CCI), which should be done early in the pharma product development process. Helium leak testing is the most chosen CCI test method due to its high sensitivity when compared to other leak test methods.

What is Helium Leak Testing and How it Evaluates Vial Integrity?

Helium leak testing is one of the Container Closure Integrity (CCI) test methods for testing the leakage of pharmaceuticals and medical devices. This method uses helium and the change in concentration is detected when it exits owing to leakage. The applications of helium leak testing include vials, pre-filled syringes, foil pouches, or cold form blister cards. Each of these packaging types is meant to keep out harmful environmental pollutants such as dirt, microorganisms, or even gases while maintaining the sterility of the medicinal product enclosed. The package is filled with helium and subjected to vacuum in this method. A helium leak detector is used to quantify the amount of helium that escapes the package. The result is expressed as a leak rate.

Why Use Helium as a Tracer Gas?

Due to the following reasons, helium is considered an ideal choice for this type of testing:

  • Helium is inert, and it is one of the smallest gas molecules.
  • Small atomic size allows it to breach pathways reliably and easily.
  • Helium is non-toxic, non-condensable, non-flammable.
  • Safe to use as it will not interact with the components being tested.
  • Helium is less expensive and readily available when compared to other tracer gases.
  • The presence of helium in the atmosphere is not more than 5ppm.

As a highly sensitive quantitative test technique, helium leak testing evaluates Container Closure System (CCS) components for parenteral applications. It offers quantitative leak rate data that significantly exceeds the detection limitations of conventional approaches. The method has proven to analyze the impact of processing factors on container closure systems, such as parenteral vial capping applications, elastomeric closure selection, or changing sealing parameters.

Readmore...
helium leak testing, helium leak detection, helium leak detector, leak test, parenteral vials
1410
24
Jan 2022

Understanding Pre-Filled Syringes Leak Detection Using Helium Mass Spectrometry

Understanding-Prefilled-Syringes-Leak-Detection-Using-Helium-Mass-Spectrometry

The use of pre-filled syringes (PFS) as a container solution for pharmaceutical products has increased significantly in recent years. It is expected that this trend will accelerate in the future decades. Pre-filled syringes have the benefit of reducing pharmaceutical waste and extending the life of the product for the pharmaceutical industry. In general, pre-filled syringes are recognized as an effective, reliable, and convenient way to dispense drugs. In addition, many injections can be self-administered without worrying about being completely transferred from a vial. It provides a safe and effective option for patients in need of long-term pharmaceutical therapies.

When compared to the conventional vial, pre-filled syringes provide extra complexity in the field of container closure integrity (CCI) inspection. The advantages of pre-filled syringes include ease of use compared to conventional vial packaging. Pre-filled syringes eliminate the necessary procedures before you use the drug in a vial. In addition, since pre-filled syringes contain the correct dose, it helps to avoid dosing errors.

Leak Testing Pre-Filled Syringes Using Helium Mass Spectrometry

The device that detects and monitors leaks within and outside a product is called Mass Spectrometer Leak Detector. This approach makes use of helium as a tracer gas, which is utilized to fill a product coupled to a detector. Helium mass spectrometry is widely known for its suitability for non-porous packaging like vials and pre-filled syringes.

The leak detector works on the basis of a sector field mass spectrometer. In a vacuum, analyzed entering gases (Helium) are ionized. Helium ions are accelerated and separated in a magnetic field using increased voltage. Using a specific detector, the ion current is converted to an electric current. The current is accelerated and displayed on the screen by leak detection units. The current measured is proportional to both, the helium concentration and the measured leakage.

Benefits of Helium Leak Testing

  • Leaks may be detected and quantified with a high degree of sensitivity.
  • Due to the inert properties of helium, it does not affect the substances under test.
  • The testing is mostly conducted in a dry, temperature-independent environment.
  • Helium leak testing has a shorter cycle time, which lowers the cost and overall processing time.

For non-porous packaging including vials, pre-filled syringes, and cartridges, helium mass spectrometry has emerged as the new leak detection standard. Unlike probabilistic traditional methods, helium leak detection methods are preferred by manufacturers and regulators for their high sensitivity, fast test time, and detection capability. Pharmaceutical industries usually choose this process during the evaluation and eligibility stages of a new packaging process, where MALL plays an important role.

Readmore...
helium mass spectrometry, helium leak testing, helium leak detection, helium leak detection methods, helium leak detector
1131
15
Dec 2021

An Overview of Helium Leak Detection Services

An-Overview-of-Helium-Leak-Detection-Services

Helium Leak Testing is used to locate and identify extremely tiny leaks in any component that can produce a differential pressure. Helium Leak Rate can be expressed quantitatively (the quantity of leak rate). The helium leak testing method is also used to examine the performance of a component or system, as well as to study or evaluate the lifetime of a product. Helium gas is primarily utilized as a leak testing medium due to its ability to detect and quantify leak rates at very low levels.

LDA offers various helium leak testing services for pharmaceuticals and medical devices. The services are as follows:

Leak Testing Services

  • Installation & Quality Assurance of Helium Leak Detector
  • Leak Detection Associates guarantees that each custom instrument comes with comprehensive service delivery, installation, and validation program that is appropriate for the regulated environments in which the instruments will be used. Prior to delivery, the LDA Engineering Technician will collaborate with delivery site personnel to confirm that the location has the appropriate gas and electrical supplies for instrument functioning. Once the instrument is on-site and in the position specified by the customer, the Engineering Technician will perform a formal Installation Qualification (IQ), Operation Qualification (OQ), and Performance Qualification (PQ). Prior to execution, these can be pre-approved by local Quality Assurance.

  • Helium Leak Detector Service Agreement
  • Leak Detection Associates recognizes that maintaining instrument performance is an important part of the business’s success. While the instruments offered by LDA are simple to use and maintain, it helps to improve productivity by proactively guaranteeing performance with an LDA Annual Service Agreement. Leak Detection Associates provides service contract plans that are customized to the unique needs and specifications. The following are examples of key components of any service program:

    1. Repair and replacement parts are available on-site at no additional charge

    2. Annual On-Site Preventative Maintenance

    3. Detailed Annual Requalification & Calibration

  •  Helium Leak Detector Calibration Services
  • Annual calibration services for all components of the test system, including internal and exterior leak standards and HSAM probes, are also available as an alternative to a full-service contract. Failure to calibrate the leakage criteria may result in a decrease in the accuracy and validity of the results over time, as well as concerns of individuals working in a CGMP or other controlled environment. A complete calibration program at regular intervals is designed to ensure proper instrument readings for the life of the device with minimal instrument downtime. LDA can set reminders when service is required once in our calibration database, ensuring that SIMS 1915+ does not skip a beat.

  • Training for Helium Leak Testing
  • Leak Detection Associates offers on-site training relevant to how the SIMS 1915+ Helium Leak Testing device will be utilized, with the objective of being a comprehensive solutions provider to the clients. More sophisticated parts of leak testing, as well as system care and maintenance, can be covered in training programs. The Leak Detection team has over 20 years of hands-on expertise and can help the organization with anything from basic knowledge and understanding of leak testing basics to specialized leak test method development and validation.

  • Helium Leak Detection Feasibility Studies
  • LDA offers dependable feasibility and method development services. Prior to procuring an instrument or moving on with outsourcing solutions, feasibility services can provide proof of concept for its intended usage, or they can assist to expand existing capabilities by designing solutions for new package systems. LDA also provides full method development utilizing industry-standard positive control techniques in the cases where clients do not have internal resources experience in the development of helium leak detection tests, or where current resources need to be expanded. Methods created at LDA can be transferred and verified at the client site, or they can be utilized frequently at LDA for lab-scale, non-cGMP research.

  • Onsite or In-House CCI for Package Systems
  • LDA offers testing capabilities at both the client's site and our location. A SIMS 1915+ purchased and installed in a controlled context can be used for client onsite testing. With hands-on expertise in cGMP and regulated laboratory and production environments, documentation procedures are quite often in line with internal and external quality standards. LDA also provides the option of bringing one of our test units to a client's site for particular investigations. In-house testing is an alternative for clients looking to analyze package systems or designs on a contract basis.

LDA provides its customers with the highest quality of services. We are the world's leading manufacturer of high sensitivity helium-based leak detection systems for the pharmaceutical and biologic industries. Our engineers and support staff are highly trained and certified, allowing us to provide professional services across a wide range of testing domains.

Readmore...
helium leak detector, helium leak testing, helium leak detection, mass spectrometry, helium mass spectrometry
1311
30
Mar 2021

Evaluating Integrity of Pre-Filled Syringes with Helium Leak Testing

Evaluating Integrity of Pre-Filled Syringes with Helium Leak Testing

What is helium leak detection?

The pharmaceutical industry has seen a significant rise in the use of pre-filled syringes in recent years. This demand is expected to accelerate over the coming decades. Pre-filled syringes offer benefits to the pharmaceutical industry in the form of reduced drug waste and increased product life span. Health care workers consider pre-filled syringes as an efficient, convenient and reliable drug administration method. However, they pose several challenges in manufacturing and require extensive testing.

Just like any other drug product, pre-filled syringes should be free from pyrogens and should be sterile. Not just that, they are expected to be biologically, chemically and physically stable throughout its shelf life. Considering the complex nature of these products, it isn’t surprising that there are many opportunities for it to fail to meet quality requirements. Defects in pre-filled syringes mainly depend on drug product design and syringe process design. Additionally, patient related issues are also an area of concern. Therefore, it is important for manufacturers to have knowledge and understanding of various tests involved to ensure patient safety.

Container Closure Integrity testing of pre-filled syringes

Sterility is the most important quality attribute associated with any pharmaceutical/ parenteral drug product. Container Closure Integrity (CCI) testing is one of the key tests performed by manufacturers so that the product is guaranteeing sterility and microbiological quality until point of use. Container closure integrity testing evaluates the ability of container closure systems to maintain a sterile barrier against possible contaminants that can deteriorate the quality of final pharmaceutical and biological products. There are multiple methods to conduct container closure integrity tests, each with its own set of benefits and limitations. For instance, techniques like dye ingress and microbiological ingress are destructive to the samples being tested. Such tests rely on statistically representative number of samples from the batch and assume that defects are uniformly present throughout the batch. On the other hand, deterministic methods are non-destructive in nature and can be used to test every unit from the batch.

Helium Leak Testing for Pre-Filled Syringes

Helium leak testing refers to the act of finding leaks in some type of enclosed or sealed system using helium as a “tracer” gas and measuring its concentration as it escapes due to leakage. Under this technique, the package is helium filled and subjected to vacuum. The amount of helium escaping the package is quantitatively measured with the help of a helium leak detector. The result is stated as a leak rate. Apart from being an effective container closure integrity test method, helium leak testing is also applicable in product design, product quality analyses, failure analyses and validation.

Why use helium as a tracer gas?

Helium is considered as an ideal choice of tracer gas because of the following reasons:

  • Helium is non-toxic, non-condensable, non-flammable.
  • It is inert, making it safe for use as it will not interact with the components being tested.
  • The atom size of helium is really small, allowing it to breach pathways reliably and easily.
  • Compared to other tracer gases, helium is less expensive and readily available.
Readmore...
helium leak testing, pre filled syringes, container closure integrity testing, helium leak detector
2078
05
Nov 2020

History of Helium Leak Detection

History of Helium Leak Detection

The First Helium Leak Detectors

The genesis for the use of helium as a method for leak detection can be traced back to the 1940’s and the Manhattan Project. The first atomic bomb created used uranium isotope 235, which is taken by way of separation from uranium-238. The separation was accomplished in a huge “diffusion” plant using microporous tubing as the diffusion medium and this process needed to be done in a manner that prevented any trace of moist ambient air in the process chambers. In essence, it was imperative that all the equipment be free of any leaks. Equipment of this size and magnitude had never before been tested to such and extreme leak detection specification. A number of various leak detection devices were tried, and they all proved unsuccessful as they could not meet the required standard for sensitivity. Eventually, a simplified mass spectrometer based on the Nier 60 spectrometer tube was chosen for leak detection and helium was the gas of choice used with it. It was determined that helium flow as sensitive as 10−6 std cm3 could easily be detected.

Major Improvements in Helium Leak Detection

In the 70+ years since the inception of the Manhattan Project, helium leak detectors have understandably been drastically improved. The size of an actual helium detector that in 1945 required a large scale, multi-story warehouse building, can now fit on a standard laboratory benchtop and the level of detection has been improved to levels that meet or exceed flows rates of 10−10–10−11 std cm3. With the inception of computers, operation of a helium detector has been fully automated. Based upon these developments, the use of helium as a medium for leak detection has become common and wide-spread practice and thus has a presence in almost every conceivable industry from refrigeration, semi-conductors, automotive and food and drug packaging components.

Modes of Operations using Helium Leak Detection

Conceptually, the principle of operations has not changed much in the past 50 years although, as noted, the size has been drastically reduced. The central piece of the helium leak detector is the cell in which the residual gas is ionised and the resulting ions accelerated and filtered in a mass spectrometer. Most of the current detectors use, as in the original design, a magnetic sector to separate the helium ions from the other gases. Permanent magnets are generally used to generate the magnetic field. The adjustment needed for the selection of the helium peak is made by varying the ion energy. At the highest sensitivity range, currents as low as femtoamperes have to be measured. This is achieved with the use of an electron multiplier in the most modern detectors. If the cell of a leak detector is not much different from the original design, the pumping system has considerably changed with the original diffusion pumps now being replaced by turbomolecular pumps or dry molecular-drag pumps. The sensitivity of the helium leak detector is given by the ratio between the helium flow through the leak and the partial pressure increase in the cell. In order to increase the sensitivity, the pumping speed of the tracer gas has to be reduced. This must be done without diminishing the pumping speed for the other gases (mainly water as leak detection usually takes place in unbaked systems) in order to keep the appropriate operating pressure for the filament emitting the ionising electrons. Selective pumping is therefore needed to provide a high pumping speed for water and a low pumping speed for helium

We hope that you have learned something regarding the history of helium leak detectors. In future installments, we will address various test methods and case studies that will provide more specific insight into the use of helium applied to the package leak testing needs of the pharmaceutical and life sciences industries.

Readmore...
helium leak detection, helium leak detector, operations using helium leak detection
3648

Popular Blogs

Tags

Leak Detection Associates Celebrates Major 2019 Milestones

Dec 27, 2019   |   11894

Leak Detection Associates (LDA), the world’s premier manufacturer of custom built, helium-based leak testing instruments for the Pharmaceutical, Biotechnology, Medical Device and Food Packaging Industries is excited to celebrate the completion of its first calendar year under new management.

The Advantages of Using Helium for Leak Testing

May 13, 2020   |   6182

The use of helium gas as a medium for leak testing dates back to the 1940’s.Using helium as the “tracer” gas enables the user to discover and measure extremely small leaks.

An Overview of 21 CFR Part 11 Compliance Requirements

Nov 02, 2020   |   5578

A review of some simple and direct questions regarding Part 11 compliance to help you to understand its requirements and implementation.

Leak Detection Associates Announces New and Updated Helium Leak Detection System

Nov 01, 2020   |   4870

Leak Detection Associates (LDA), the world’s premier manufacturer of custom built, helium-based leak testing instruments is excited to announce the launch of its newest and most advanced helium leak detection system, the SIMS Model 1915 that is engineered incorporating industry-leading Agilent Technologies components and is custom designed to meet the stringent requirements of clients in FDA-regulated industries.

2019 PDA Container Closure Integrity Testing Workshop Presentation

Nov 03, 2020   |   4535

The 2019 PDA Container Closure Integrity Testing Workshop in Gothenburg, Sweden, had the following presentation that was given as a 20 minute introduction to the use of helium leak detection for container closure integrity testing (CCIT).
Popup
